LPS

0105
- Saves space and minimizes investment cost
- Optimized AGV (Automated Guided Vehicle) technology with single mast and single fork structure
- Simple installation
- Facilitates the realisation and exploitation of DN Solutions horizontal machining centers’ productivity
- Facilitates flexible production

Highlight

Specification of Machine Tools


  LPS 4000 LPS 5000
Available Model
NHP 4000 HC 400Ⅱ HP 4000Ⅱ
NHP 5000 HC 500Ⅱ HP 5100Ⅱ
Pallet Dimension 400 mm x 400 mm 500 x 500 mm
Workpiece Diameter 600 mm 800 mm
Workpiece Height 800 mm 900 / 930 mm
Workpiece Weight 400 kg 500 kg, 700 kg
Travelling (X) Speed 60 m/min [Load], 90 m/min [Unload]
Lifting (Y) Speed 10 m/min [Load], 20 m/min [Unload]
Forking (Z) Speed 20 m/min [Load], 50 m/min [Unload]
Axis Control Servo
Forking Type Single Fork (Telescopic Mechanism)
Turntable Indexing 45˚
Power Supply (AGV) Trolley Bar
Communication
(AGV<-> Main Controller)
Optical
Number of Machines 1 ~ 7 (Aux. +1)
Number of Setup Stations 1 ~ 4
Number of Pallet 12 ~ 72 Ea
Dimension(Basic) 6980 mm [L] x 2400 mm [W]

Specification of Machine Tools


Description LPS 5500 LPS 6300 LPS 8000
Available Model
NHM 5000 NHP 5500
NHM 6300 NHP 6300
NHM 8000 NHP 8000
Pallet Dimension 500 mm x 500 mm 630 mm x 630 mm 800 mm x 800 mm
Workpiece Diameter 850 mm 1050 mm 1450 mm
Workpiece Height 1100 mm 1350 mm 1400 mm
Workpiece Weight 800 kg 1200 kg 2000 kg
Number of Machines     1 ~ 7
Number of Setup Stations     1 ~ 4
Number of Pallet 12 ~ 72 ea 10 ~ 70 ea 8 ~ 72 ea
Dimension(Basic) 7824 mm [L] x 2400 mm [W] 7904 mm [L] x 785 mm [W] 8952 mm [L] x 3500 mm [W]
  • * For detailed information, please contact DN Solutions’ dealerships.
